Vessel Motions – Superposition of Harmonics

Previous pageNext page

The high frequency response of the vessel reference point in local degree of freedom i to a Stokes V wave when you nominate the Superposition of Harmonics option is defined by:

       (1)

where:

is the vessel RAO in degree of freedom i, which is a function of wave heading and wave frequency

is the vessel phase angle in degree of freedom i, which is also a function of and

Remaining symbols are as previously defined. With this option, the vessel response is a summation of five components, which correspond to the “components” in the expression for water surface elevation in the Stokes v Wave - Theory (Eq.3). RAO values and phase angles corresponding to each component in the Stokes v Wave - Theory (Eq.3) are extracted from the user-specified data in the usual way, and the vessel response is found by summing over the five terms in a similar manner as would be used in a random sea. Obviously for this exercise to be meaningful RAOs and phase angles must be defined over the full range of circular frequencies from to .
